Ahlbrandt

  • Ahlbrandt Ozone Converter Catalytic Air Purifier

    Ahlbrandt Ozone Converter Catalytic Air Purifier

  • Ahlbrandt Corona Treater for Blown Film Extrusion
    Ahlbrandt Corona Treater for Blown Film Extrusion Ahlbrandt Corona Treater for Blown Film Extrusion

    Ahlbrandt Corona Treater for Blown Film Extrusion

    • Large cover allows for easy access and maintenance;
    • Easy web threading;
    • Swiveling electrode for simple handling;
    • Quick changeover of treater roller;
    • Utilizing robust parts, prolonged service life;
    • Simple and precise segment adjustment;
  • Ahlbrandt Corona Treater (Ceramic Electrode)

    Ahlbrandt Corona Treater (Ceramic Electrode)

    • 180-degree rotation for easy operation;
    • Easy and quick electrode changeover without tools up to 2000mm working width;
    • Electrode options: 2 ceramic electrodes, 4 ceramic electrodes, 5 ceramic electrodes, metal rod electrodes, metal profile electrodes;
  • Ahlbrandt Rotor Spray System

    Ahlbrandt Rotor Spray System

    • Spray water or chemicals (in solution or dispersions);
    • Spray liquids with maximum viscosity of 50MPa·s (solution) and 200MPa·s (dispersions), particle size up to 5μm;
    • pH 4 to 8 (2 to 12 optional), temperature up to 60℃;
    • Spray 0.5 to 150g/m2 (depending on production speed);
    • Can be applied on either or both sides of a substrate;
    • Moistening can be controlled according to external moisture measurement value;
    • Tank volume 60L, with automatic refill level control;
    • Rinsing program for chemical edition;
    • Spray width up to 5.5mm;
Ahlbrandt Corona Generator

Ahlbrandt Corona Generator

Technical Data
  • Power range: 1-40kW;
  • Siemens KTP 700 touch panel;
  • Power display in kW/corona dose;
  • Thickness detection is adjustable on display;
  • Precise transverse recess for bag printing;
  • Multiple languages selectable;
Options
  • Power adjustment via analog or field bus;
  • Process monitoring with memory and USB connection;
  • UL/CSA version;
Advantages
  • Modular design for simple replacement of parts;
  • Integrated diagnostic system, more convenient service;
  • Efficiency optimized by regulating resonance frequency;
  • Electrode defect detection;
  • Web server for on-site and remote service;
  • Maximized output due to high efficiency;
Field Bus Connection
  • Profinet, Profibus (others on request);
  • Complete control via customer PLC;
  • Status analysis for rapid service;
Options
  • Remote maintenance via network access;
  • Operation on additional display;
